EYEPIECE
With an extended field of view of 22 mm, the Achios-X Observer proves its usefulness by reducing the need of moving the specimen over the stage, which is highly appreciated in demanding applications
HEADS
An impressive line of heads to choose from:
Apart from the standard Siedentopf trinocular with 30° inclined tubes, there is the optional ergonomic tilting head (0° – 35°), the face-to-face dual head and last but not least, multi-head systems with 2, 3 or 5 heads
OBJECTIVES
The Achios-X observer comes with Infinity corrected achromatic Plan, Plan Phase or Plan Semi-Apochromatic EIS objectives and are 60 mm parfocal and have a M25 mounting thread
STAGE
The Achios-X Observer comes complete with a generously sized, hard coated, rackless mechanical stage, meticulously designed for enhanced safety. Free from any sharp edges protruding from the microscope’s sides, this stage ensures a secure and worry-free experience. Suitable for two slides and allows single handed placement of slides
CONDENSERS
Depending the configuration, the Achios-X Observer is supplied with
- Standard Abbe Condenser
- Zernike phase condenser includes telescope and green filter
- Swing-out Abbe Condenser
- Dark field condenser (Dry)
- Dark field condenser (Oil)
ILLUMINATION
The Köhler illumination of the Achios-X Observer provides the most uniformly illuminated and bright field of view
NOSEPIECE
Experience the ease of an intuitive quintuple or an optional sixtuple nosepiece on ball- bearings, equipped with gripped ring for effortless and precise rotation
LIGHT AND COLOR TEMPERATURE CONTROL
The Achios-X Observer introduces Smart Light Control. This intelligent function memorizes the light intensity level for each objective. The color temperature of the NeoLED light source can be adjusted and stored. This innovation not only heightens comfort but also saves valuable time during routine magnification shifts. The eco-friendly NeoLED light source is both environmentally conscious and built to endure
CSS – CABLE STORAGE SYSTEM
Allows users to easily stow away excess cable length into the back of the instrument during operation and to roll up the power cable for easy storage
CARRYING GRIP
The integrated carrying grip at the back of the microscope ensures safe transportation of the microscope
NEOLED
The innovative NeoLED™ design is a combination of a custom LED and a specially designed thin lens with a short focal length in order to obtain four main benefits:
- More oblique light from the NeoLED™ light source can be captured, which increases the light output significantly
- Less energy is required to achieve this level of light intensity
- The larger aperture of NeoLED™ allows the optical system of the microscope to produce images at higher resolutions, very close to the theoretical diffraction limit of the optics
- Super long life span, up to 50.000 hrs nominal, L70 norm
PACKAGING
Supplied with power cord, dust cover, screwdriver, user manual and 5 ml immersion oil for models supplied with a 100x objective
Images are reference only. Actual product may be different.
